Valvola di Carica 'E160M24503'

E160M24503

Descrizione

Countries: Argentina, Colombia.


Data Sheet
TECHNICAL DATA SHEET
VALVOLA DI CARICO ‘MONOBLOCCO’
- Max working pressure: 260 bar
- Working temperature : -40 +120 °C
- No return valve
- Agreement: ECE R110
Inlet/Outlet pipe
connection
External pipe
connection
Ø Pico
M12X1G” 1/212.6 Ø
1/4” NPTG” 1/212.6 Ø
